Specifications of the RC300S G5

Format 19 (1HE), Short rack housing
Assembly Installation angle
Dimensions (W/H/D) 43,0cm x 4,4cm x 20,0cm
User (max.) 100
Hard disc SSD
Temperature range (operation) 0°C - 40°C
Temperature range (storage) -20°C - 60°C

Performance of the RC300S G5

Firewall throughput 13 GBit/s
VPN throughput 1.5 GBit/s
HTTP proxy with AV 1.0 GBit/s
AES hardware accelerator yes (Intel)
Power supply simple
Power supply unit (internal) 110-240V (50-60Hz)
Power consumption ~45 W

Connections of the RC300S G5

LAN ports 6x 1 GBit/s
Expansion slots 1x
SFP ports (OnBoard) 2x 1 GBit
Connections - HDMI
- 2x USB 3.0
- Console port
